12D1C-05S03NM

https://isatronick.be/web/image/product.template/6344/image_1920?unique=b3ceb62

AMOUNT ​​Unit Price
1 ​ ​2,25 € ​
100 ​ ​1,93 €​
1.000 ​ ​1,70 €
5.000 ​ ​Price on request

2.25 € 2.25 EUR 2.25 € VAT Excluded

Not Available For Sale

DC-DC Converter 12D1C-NM SERIES

- 7PIN SIP Package

- Continuous short-circuit protection

- The leakage current < 1.5μA

- Isolation capacitance as low as 4pF

- Creepage &clearance distance > 5mm

- High efficiency up to 83%

- Unregulated output types

- 5000Vac or 6000Vdc isolation

- Operating temperature:-40℃ to +105℃

- Industry standard pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report
- UL/cUL/IEC/EN 60601-1 approved, CB-Report
- EMC Standard of EMI EN55032:2015 Approved
- EMC Standard of EMS EN55035:2017 Approved
- Medical EMC Standard of EMI EN 60601-1-2:2014+A1:2020 Approved.
- Medical EMC Standard of EMS EN 60601-1-2:2015+A1:2021 Approved

    This combination does not exist.

    Contact Us
    RoHS

    Terms and Conditions

    Specifications

    Brand YUAN DEAN SCIENTIFIC
    Input Voltage 5Vdc
    Output Voltage 3,3Vdc
    Output Current 303mA
    Efficiency 75%TYP
    Capacitive Load 2200µF
    Isolation 6KVDC
    Package SIP7
    Output Type Unregulated
    Application EN 60601 (medical)
    Number of Outputs Single
