  2. 12DC-09D09NPH6

12DC-09D09NPH6

https://isatronick.be/web/image/product.template/6473/image_1920?unique=f3fc5a0

DC-DC Converter 12DC SERIES
- 7PIN SIP Package
- No-load input current as low as 5mA
- Continuous short-circuit protection
- High Efficiency up to 87%
- Unregulated Output Types
- 1.5KVDC ~ 6KVDC Isolation
- Operating Temperature:-40℃ to +105℃
- Industry Standard Pinout
- UL/cUL/IEC/EN 62368-1 approved, CB-Report
- EMC Standard of EMI EN55032:2015 Approved
- EMC Standard of EMS EN55035:2017 Approved

AMOUNT ​Unit Price
1 ​ ​ ​3,33€
50 ​ ​2,59€
100 ​ ​1,72€
500 ​ ​1,52€
1.000 ​ ​1,19€
5.000 ​ ​Price on request

3.33 € 3.33 EUR 3.33 € VAT Excluded

Not Available For Sale

DC-DC Converter 12DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

- 1.5KVDC ~ 6KVDC Isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved

  • Brand
  • Input Voltage
  • Output Voltage
  • Output Current
  • Efficiency
  • Capacitive Load
  • Isolation
  • Power
  • Package

This combination does not exist.

Contact Us
RoHS

Terms and Conditions

Specifications

Brand YUAN DEAN SCIENTIFIC
Input Voltage 9Vdc
Output Voltage ±9Vdc
Output Current ±56mA
Efficiency 83%TYP
Capacitive Load ±470µF
Isolation 6KVDC
Power 1W
Package SIP7
