Resistance (Ω)

Wire Wound
Fixed Power Wirewound
Symmetry Resistors And/Or Capacitors Discharge
Thick Film Power

Product	Datasheet	Brand	Resistance (Ω)	Max Voltage	Rated Power	Temperature Rise (°C/W)	Tolerance
2CS 270R 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.35 € 0.35000000000000003 EUR	Data sheet	ATE	270Ω	130V	3W	91	N/A
2CS 27R 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.35 € 0.35000000000000003 EUR	Data sheet	ATE	27Ω	130V	3W	91	N/A
2CS 2K0 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.42 € 0.42 EUR	Data sheet	ATE	2kΩ	130V	3W	91	N/A
2CS 2K2 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.42 € 0.42 EUR	Data sheet	ATE	2,2kΩ	130V	3W	91	N/A
2CS 2K4 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.42 € 0.42 EUR	Data sheet	ATE	2,4kΩ	130V	3W	91	N/A
2CS 2K7 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.0 EUR	Data sheet	ATE	2,7kΩ	130V	3W	91	N/A
2CS 2R0 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.35 € 0.35000000000000003 EUR	Data sheet	ATE	2Ω	130V	3W	91	N/A
2CS 2R2 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.35 € 0.35000000000000003 EUR	Data sheet	ATE	2,2Ω	130V	3W	91	N/A
2CS 2R4 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.35 € 0.35000000000000003 EUR	Data sheet	ATE	2,4Ω	130V	3W	91	N/A
2CS 2R7 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.35 € 0.35000000000000003 EUR	Data sheet	ATE	2,7Ω	130V	3W	91	N/A
2CS 300R 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.35 € 0.35000000000000003 EUR	Data sheet	ATE	300Ω	130V	3W	91	N/A
2CS 30R 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.35 € 0.35000000000000003 EUR	Data sheet	ATE	30Ω	130V	3W	91	N/A
2CS 330R 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.35 € 0.35000000000000003 EUR	Data sheet	ATE	330Ω	130V	3W	91	N/A
2CS 33R 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.35 € 0.35000000000000003 EUR	Data sheet	ATE	33Ω	130V	3W	91	N/A
2CS 360R 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.35 € 0.35000000000000003 EUR	Data sheet	ATE	360Ω	130V	3W	91	N/A
2CS 36R 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.35 € 0.35000000000000003 EUR	Data sheet	ATE	36Ω	130V	3W	91	N/A
2CS 390R 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.35 € 0.35000000000000003 EUR	Data sheet	ATE	390Ω	130V	3W	91	N/A
2CS 39R 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.35 € 0.35000000000000003 EUR	Data sheet	ATE	39Ω	130V	3W	91	N/A
2CS 3K0 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.42 € 0.42 EUR	Data sheet	ATE	3kΩ	130V	3W	91	N/A
2CS 3K3 5% Wirewound Resistors – CS Series Easy replacement for vitreous enamel resistors Multi-layer silicone coating for maximum wire protection Operating temperature range: -55°C to +350°C Ceramic core for durability and uniformity Low temperature coefficient and excellent stability Fully welded construction for high reliability Standard tolerance: 5% Optional tolerances available: 3%, 2%, 1% and 0.5% upon request 0.42 € 0.42 EUR	Data sheet	ATE	3,3kΩ	130V	3W	91	N/A
