DC-DC Converters

  • DC-DC Converters
  • AC-DC Converters
Product
Datasheet
Brand
Power
Input Voltage
Output Voltage
Output Current
Efficiency
Capacitive Load
Isolation
Package
Application
14DC-12S09NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 12Vdc 9Vdc 112mA 85%TYP 1000µF 1,5KVDC SIP7 N/A
14DC-12S05NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 12Vdc 5Vdc 200mA 82%TYP 2400μF 1,5KVDC SIP7 N/A
14DC-12S03NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 12Vdc 3,3Vdc 303mA 78%TYP 2400μF 1,5KVDC SIP7 N/A
14DC-09D24NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 9Vdc ±24Vdc ±21mA 85%TYP ±47µF 1,5KVDC SIP7 N/A
14DC-09D15NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 9Vdc ±15Vdc ±34mA 84%TYP ±220µF 1,5KVDC SIP7 N/A
14DC-09D12NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 9Vdc ±12Vdc ±42mA 84%TYP ±220µF 1,5KVDC SIP7 N/A
14DC-09D09NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 9Vdc ±9Vdc ±56mA 83%TYP ±470µF 1,5KVDC SIP7 N/A
14DC-09D05NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 9Vdc ±5Vdc ±100mA 82%TYP ±1200μF 1,5KVDC SIP7 N/A
14DC-09D03NP

https://isatronick.be/web#id=6277&cids=1&menu_id=264&action=398&model=product.template&view_type=form
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 9Vdc ±3.3Vdc ±151mA 76%TYP ±1200μF 1,5KVDC SIP7 N/A
14DC-09S24NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 9Vdc 24Vdc 42mA 85%TYP 100µF 1,5KVDC SIP7 N/A
14DC-09S15NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 9Vdc 15Vdc 67mA 84%TYP 330μF 1,5KVDC SIP7 N/A
14DC-09S12NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 9Vdc 12Vdc 84mA 84%TYP 470µF 1,5KVDC SIP7 N/A
14DC-09S09NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 9Vdc 9Vdc 112mA 83%TYP 1000µF 1,5KVDC SIP7 N/A
14DC-09S03NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 9Vdc 3,3Vdc 303mA 76%TYP 2400μF 1,5KVDC SIP7 N/A
14DC-05D24NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 5Vdc ±24Vdc ±21mA 85%TYP ±47µF 1,5KVDC SIP7 N/A
14DC-05D15NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 5Vdc ±15Vdc ±34mA 84%TYP ±220µF 1,5KVDC SIP7 N/A
14DC-05D09NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 5Vdc ±9Vdc ±56mA 83%TYP ±470µF 1,5KVDC SIP7 N/A
14DC-12S12NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 5Vdc 12Vdc 84mA 85%TYP 680µF 1,5KVDC SIP7 N/A
14DC-05D03NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 5Vdc ±3.3Vdc ±151mA 76%TYP ±1200μF 1,5KVDC SIP7 N/A
14DC-05S24NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 1W 5Vdc 24Vdc 42mA 85%TYP 100µF 1,5KVDC SIP7 N/A
