Converters and Power Supplies

  • DC-DC Converters
  • AC-DC Converters
Product
Datasheet
Brand
Input Voltage
Output Voltage
Output Current
Isolation
Power
Package
14DC-15S09NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 15Vdc 9Vdc 112mA 1,5KVDC 1W SIP7
14DC-15S12NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 15Vdc 12Vdc 84mA 1,5KVDC 1W SIP7
14DC-15S15NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 15Vdc 15Vdc 67mA 1,5KVDC 1W SIP7
14DC-15S24NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 15Vdc 24Vdc 42mA 1,5KVDC 1W SIP7
14DC-24D03NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 24Vdc ±3.3Vdc ±151mA 1,5KVDC 1W SIP7
14DC-24D05NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 15Vdc ±5Vdc ±100mA 1,5KVDC 1W SIP7
14DC-24D09NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 24Vdc ±9Vdc ±56mA 1,5KVDC 1W SIP7
14DC-24D12NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 24Vdc ±12Vdc ±42mA 1,5KVDC 1W SIP7
14DC-24D15NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 24Vdc ±15Vdc ±34mA 1,5KVDC 1W SIP7
14DC-24D24NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 24Vdc ±24Vdc ±21mA 1,5KVDC 1W SIP7
14DC-24S03NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 24Vdc 3.3Vdc 303mA 1,5KVDC 1W SIP7
14DC-24S05NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 24Vdc 5Vdc 200mA 1,5KVDC 1W SIP7
14DC-24S09NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 24Vdc 9Vdc 112mA 1,5KVDC 1W SIP7
14DC-24S12NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 15Vdc 12Vdc 84mA 1,5KVDC 1W SIP7
14DC-24S15NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 24Vdc 15Vdc 67mA 1,5KVDC 1W SIP7
14DC-24S24NP

DC-DC Converter 14DC SERIES

- 7PIN SIP Package

- No-load input current as low as 5mA

- Continuous short-circuit protection

- High Efficiency up to 87%

- Unregulated Output Types

-  1.5KVDC ~ 3KVDC isolation

- Operating Temperature:-40℃ to +105℃

- Industry Standard Pinout

- UL/cUL/IEC/EN 62368-1 approved, CB-Report

- EMC Standard of EMI EN55032:2015 Approved

- EMC Standard of EMS EN55035:2017 Approved
3.33 € 3.33 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC 24Vdc 24Vdc 42mA 1,5KVDC 1W SIP7
GA10M-S05

AC-DC Converter Module, Medical Application, GA10M Series

-  Universal input 80~264VAC.
-  Medical safety design refer to (2 X MOPP) according to ANSI/AAMI            ES60601-1 and IEC/EN60601-1.
- Suitable for BF application with appropriate system consideration.
- No load power consumption<0.1W.
- Extremely low leakage current.
- EMI class B for class Ⅱ configuration.
- Protection: short circuit/overload/over voltage/over temperature.
- No minimum load required.
- 2 years warranty.
- ROHS compliant
8.10 € 8.1 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC N/A 5Vdc 2000mA N/A 10W DIL4
GA10M-S12

AC-DC Converter Module, Medical Application, GA10M Series

- Universal input 80~264VAC.
- Medical safety design refer to (2 X MOPP) according to ANSI/AAMI           ES60601-1 and IEC/EN60601-1.
- Suitable for BF application with appropriate system consideration.
- No load power consumption<0.1W.
- Extremely low leakage current.
- EMI class B for class Ⅱ configuration.
- Protection: short circuit/overload/over voltage/over temperature.
- No minimum load required.
- 2 years warranty.
- ROHS compliant
8.10 € 8.1 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC N/A 12Vdc 850mA N/A 10,2W DIL4
GA10M-S15

AC-DC Converter Module, Medical Application, GA10M Series

-  Universal input 80~264VAC.
-  Medical safety design refer to (2 X MOPP) according to ANSI/AAMI
   ES60601-1 and IEC/EN60601-1.
- Suitable for BF application with appropriate system consideration.
- No load power consumption<0.1W.
- Extremely low leakage current.
- EMI class B for class Ⅱ configuration.
- Protection: short circuit/overload/over voltage/over temperature.
- No minimum load required.
- 2 years warranty.
- ROHS compliant
8.10 € 8.1 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC N/A 15Vdc 670mA N/A 10W DIL4
GA10M-S24

AC-DC Converter Module, Medical Application, GA10M Series

- Universal input 80~264VAC.
- Medical safety design refer to (2 X MOPP) according to ANSI/AAMI
   ES60601-1 and IEC/EN60601-1.
- Suitable for BF application with appropriate system consideration.
- No load power consumption<0.1W.
- Extremely low leakage current.
- EMI class B for class Ⅱ configuration.
- Protection: short circuit/overload/over voltage/over temperature.
- No minimum load required.
- 2 years warranty.
- ROHS compliant
8.10 € 8.1 EUR
Data sheet
RoHS
YUAN DEAN SCIENTIFIC N/A 24Vdc 460mA N/A 11W DIL4
