DC-DC Converters
AC-DC Converters

Product	Datasheet	Brand	Power	Input Voltage	Output Voltage	Output Current	Efficiency	Capacitive Load	Isolation	Package	Application
12DC-05S03NPH3 DC-DC Converter 12DC SERIES - 7PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 6KVDC Isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	5Vdc	3,3Vdc	303mA	76%TYP	2400μF	3KVDC	SIP7	N/A
12DC-03D24NPH3 DC-DC Converter 12DC SERIES - 7PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 6KVDC Isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	3,3Vdc	±24Vdc	±21mA	85%TYP	±47µF	3KVDC	SIP7	N/A
12DC-03D15NPH3 DC-DC Converter 12DC SERIES - 7PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 6KVDC Isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	3,3Vdc	±15Vdc	±34mA	84%TYP	±220µF	3KVDC	SIP7	N/A
12DC-03D12NPH3 DC-DC Converter 12DC SERIES - 7PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 6KVDC Isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	3,3Vdc	±12Vdc	±42mA	84%TYP	±220µF	3KVDC	SIP7	N/A
12DC-03D09NPH3 DC-DC Converter 12DC SERIES - 7PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 6KVDC Isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	3,3Vdc	±9Vdc	±56mA	83%TYP	±470µF	3KVDC	SIP7	N/A
12DC-03D05NPH3 DC-DC Converter 12DC SERIES - 7PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 6KVDC Isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	3,3Vdc	±5Vdc	±100mA	82%TYP	±1200μF	3KVDC	SIP7	N/A
14DC-03S03NP DC-DC Converter 14DC SERIES - 7PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 3KVDC isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	3,3Vdc	3,3Vdc	303mA	76%TYP	2400μF	1,5KVDC	SIP7	N/A
12DC-03S24NPH3 DC-DC Converter 12DC SERIES - 7PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 6KVDC Isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	3,3Vdc	24Vdc	42mA	85%TYP	100µF	3KVDC	SIP7	N/A
12DC-03S15NPH3 DC-DC Converter 12DC SERIES - 7PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 6KVDC Isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	3,3Vdc	15Vdc	67mA	84%TYP	330μF	3KVDC	SIP7	N/A
12DC-03S12NPH3 DC-DC Converter 12DC SERIES - 7PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 6KVDC Isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	3,3Vdc	12Vdc	84mA	84%TYP	470µF	3KVDC	SIP7	N/A
12DC-03S09NPH3 DC-DC Converter 12DC SERIES - 7PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 6KVDC Isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	3,3Vdc	9Vdc	112mA	83%TYP	1000µF	3KVDC	SIP7	N/A
12DC-03S05NPH3 DC-DC Converter 12DC SERIES - 7PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 6KVDC Isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	3,3Vdc	5Vdc	200mA	82%TYP	2400μF	3KVDC	SIP7	N/A
12DC-03S03NPH3 DC-DC Converter 12DC SERIES - 7PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 6KVDC Isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	3,3Vdc	3,3Vdc	303mA	76%TYP	2400μF	3KVDC	SIP7	N/A
13DC-03S03N2P DC-DC Converter 13DC SERIES -4PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 3KVDC isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	3,3Vdc	3,3Vdc	303mA	76%TYP	2400μF	1,5KVDC	SIP4 10mm	EN 62368 (ITE / Industry)
13DC-05S03N2P DC-DC Converter 13DC SERIES -4PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 3KVDC isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	5Vdc	3,3Vdc	303mA	76%TYP	2400μF	1,5KVDC	SIP4 10mm	EN 62368 (ITE / Industry)
13DC-03S05N2P DC-DC Converter 13DC SERIES -4PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 3KVDC isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	3,3Vdc	5Vdc	200mA	82%TYP	2400μF	1,5KVDC	SIP4 10mm	EN 62368 (ITE / Industry)
13DC-05S05N2P DC-DC Converter 13DC SERIES -4PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 3KVDC isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	5Vdc	5Vdc	200mA	82%TYP	2400μF	1,5KVDC	SIP4 10mm	EN 62368 (ITE / Industry)
13DC-12S12N2P DC-DC Converter 13DC SERIES -4PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 3KVDC isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	12Vdc	12Vdc	42mA	85%TYP	330μF	1,5KVDC	SIP4 10mm	EN 62368 (ITE / Industry)
13DC-12S05N2P DC-DC Converter 13DC SERIES -4PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 3KVDC isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	12Vdc	5Vdc	200mA	82%TYP	2400μF	1,5KVDC	SIP4 10mm	EN 62368 (ITE / Industry)
14DC-12S15NP DC-DC Converter 14DC SERIES - 7PIN SIP Package - No-load input current as low as 5mA - Continuous short-circuit protection - High Efficiency up to 87% - Unregulated Output Types - 1.5KVDC ~ 3KVDC isolation - Operating Temperature:-40℃ to +105℃ - Industry Standard Pinout - UL/cUL/IEC/EN 62368-1 approved, CB-Report - EMC Standard of EMI EN55032:2015 Approved - EMC Standard of EMS EN55035:2017 Approved 3,33 € 3.33 EUR	Data sheet	YUAN DEAN SCIENTIFIC	1W	12Vdc	15Vdc	67mA	87%TYP	330μF	1,5KVDC	SIP7	N/A
